How bit Works?

Bit is the component collaboration platform. Bit leverages component reusability by providing an ecosystem for sharing components between applications and across repositories.

Components are the building blocks of modern web architectures. Encapsulated and reusable components with focused and well-defined APIs let developers build more robust software applications more quickly.

The major frontend frameworks - React, Vue, and Angular - all share the concept of using component-based architecture to compose state-of-the-art applications. Even browsers themselves are backing components as an inherent feature by supporting the Web Components standard.

Bit adds a semantic layer on top of repositories that maps files into components. This extra layer provides Bit with robust capabilities in making the component reusable across projects.

Understanding Bit Components

A Bit component is a reusable piece of code, such as

• A react, Vue or Angular component
• Shared stylesheet (e.g., CSS, SCSS) or stylesheets
• Utility function used by the application.

The exact boundaries of the component are a design decision. It is possible to package a whole library as a single Bit component or split each functional piece as a separate component.

From a bird's-eye view, code options can boil down to these:

// All components packaged as a single Bit component
import { Text, Card, Button } from '@bit/scope.library';

//Each component packaged as a Bit component
import { Text } from '@bit/scope.text';
import { Card } from '@bit/scope.card';
import { Button } from '@bit/scope.button';

While the first option is possible with Bit, Bit is geared towards working with the second option, where each UI component is a separate Bit component. When working with smaller discrete components, each one versioned on its own, you can enjoy a broad set of benefits:

• The consumer of the components gets a smaller bundle size, as they only get the component they need.
• Each component is versioned separately, so the version numbers can reflect the changes made in the component using semver conventions (patch, minor, major).
• The consumer is not bound to consume a single version of all the components, so if a particular component is faulty, they can retain an older version of it, while advancing other components.
• Shorter release cycles for each component, as there is no need to "wait" on changes for the whole library.
• When local changes are required, it is simpler to get the source code of just one component and fix it or change it locally, rather than the full library.
• Bit provides a smart tagging mechanism. Making changes to a component triggers an optional version bumping to all components that depend on it.

Releasing design systems series by Nathan Curtis further enhances smaller components benefits.

Structure

For each component Bit stores three elements:

• The source code (including code itself, testing and documentation)
• Dependency graph
• Tools & Configuration

Source code

A component starts its Bit journey by specifying the source files.
Typically, the component’s content is not just the source code itself and can include additional files that are related, such as the styling files, assets (images, fonts), test code, documentation.
Bit maps the set of files to a component, with a particular file as the entry point for the component. Bit marks the entry point file as main.

Dependency graph

When adding sources to a Bit component, Bit analyzes all the dependencies it includes (i.e. import and require statements in the code). Bit then creates a model of all the dependencies of the component.
The dependencies include the following:

• NPM packages installed as node_modules
• Bit components installed as node_modules
• Bit components imported into the workspace
• Bit components created locally from local files

The dependency graph makes a component self-contained and allows for moving the component around projects without losing any references.

Tools and Configuration

Bit links each component with a set of tools and configurations. The tools are dedicated components that can take the component source code and its dependency graph and generate some desired result.
The most common tools linked to components are:

• Compiler: compiles or transpiles the original files and generates built artifacts. The artifacts are consumable by applications or other components. Compilers are specific to frameworks and usually even to flavors of the framework, as they contain the configuration required to run them.
• Tester: An extension that runs the tests associated with the component and returns a status.

Lifecycle

Here is a bird's-eye view of a component life cycle:

Producing components

• Track: A component is initiated inside a workspace by specifying the files that comprise the component. In this workspace, this is an authored component.
• Version: Tagging a version seals the contents of the files and the metadata under this version. If the component has a compiler, Bit builds the component and seals the built artifacts as well (think of it as similar to a git commit and npm publish at the same time).
• Export: Exporting the component creates a unique ID for the component. The unique id is the remote scope name and the local component name, including any namespaces. The export command sends a copy of the files and metadata to the remote server.

Consuming components

Once residing on a remote scope, the component is available for consumption by other workspaces. The ways to consume the component are by either installing it or importing it.

• Install: Bit install adds the package as a regular NPM package to the node_modules folder. When installing a component (bit install / npm install / yarn add), the component is added to the package.json, pointing to the installed version: "@bit/user.scope.tabs": "0.0.2". Changes to the code of an installed component are not saved.
• Import: Bit import adds the component to the workspace components folder and tracks its modifications. On an import, you can see that the package.json points to a local file: "@bit/user.scope.tabs": "file:./components/tabs". Code modifications are tracked and can be exported as a new version.
• Eject: If a new version is exported, it is possible to revert to an installed component. In this case, the package.json is updated back to "@bit/user.scope.tabs": "0.0.3"

Isolation

Components let you split your code into independent, reusable pieces, and think about each piece in isolation. Bit manages each component separately to ensure its independence and reusability.
Wrapping each component in a detached environment reduces the risk of a component misbehaving when moved between different projects and applications.
For each component, Bit builds a context disconnected from the rest of the project. Inside this context, Bit creates a full environment required for building, testing and rendering the component.

A component context is similar to how a separate repo for an NPM package looks:

• The source code of the component only (these are the files tracked in the component)
• The NPM packages required by the component
• Additional Bit components utilized by this component
• Package.json pointing to the component files
• Environment configurations required for processing the component. Such as tsconfig.json file for Typescript-based components or .babelrc for babel-based components.

All the information about the component is encapsuled as part of the component data. A component imported into a new project comes bundled with all the configuration data needed.

Characteristics

Component id

Each component has a unique id. We use the Component id when installing the component, importing it, or utilizing it in the project.
A full ID of a component comprises of the scope name, namespaces, and the short Id:
owner.scope/namespace/namespace/short-id; Using namespaces allows organization of components in the same way we organize files inside folders.
However, the above name is not usable when installing the components with package managers (Yarn, NPM). Then, the name translates to:
@registry-name.owner.scope.namespace.namespace.short-id. For components stored on bit.dev, the registry name is always @bit.
To use the component in the code, you should import as follow:

import { something } from '@bit/owner.scope.namespace.namespace.short-id';

Main file

Each component has a main file, which is an entry point to the component. The main file is one of the source files. Bit starts from the main file and checks all the dependencies the component has. All imports should reference NPM packages, e.g. 'lodash' or files included in the component or other components.

Versions

Bit components are versioned using Semantic Versioning. Creating a new version of a component is done by tagging it with a new version. Bit then snapshots all the component's files and dependencies. New versions of components are shareable to remote scopes using the bit export command.

Components Management

Bit is a CLI based tool for working with components. Bit stores components in two formats:

• Inside a scope, Bit stores the semantic representation of Bit components as objects with all their history and relationships.
• Inside the workspace, Bit stores the file representation of a single version of the component.

Workspace

Bit creates a workspace inside a working project when running the init command. From that point on, you can create and checkout components from the local scope into the Bit workspace and use them in the project.

The workspace has:

• Workspace configuration - contains information about the project that contains the Bit components, such as the package manager used for installing it, the compilers and testers used by the components, and the components' code location. The workspace configuration is stored under the bit section in the package.json or as a separate bit.json file at the workspace root.
• Components index - defines the files that comprise each component. Bit stores the index in the .bitmap file at the workspace root.

Inside a workspace two types of components exist:

• Authored components
• Imported components

Scope

A scope may exist inside a workspace or without a workspace. Components are shared between scopes using import and export commands.
The components are stored as content addressable storage as a storage efficient mechanism.
The scope resides under the .bit folder. Inside a workspace which is also a git project, it defaults to .git/bit folder.

Use the bit tag and checkout commands to transfer a single version of a component between the local scope and the workspace.

Note: Bit workspace and scope are highly inspired by the mechanisms used in Git for managing a git workspace and a git repository, so if you are familiar with those, it is easier to understand Bit.

Remote Scope

The remote scope is a scope that resides on a server, also called a bare scope, since it is defined outside a workspace.
A remote scope is used for sharing components, so it is, in fact, a place where components are exported to and imported from.

A user can set up a Bit Server that holds remote scopes for sharing components between Bit workspaces. Alternatively, users can use bit.dev for storing remote scopes of components.

The diagram below highlights the main commands that move components between the local workspace, the map index (.bitmap file), the local scope (.git/.bit) and the remote scope:
